RDS5180 80KG High Torque Digital Servo 180° Metal Gear Dual Shaft

RDS5180 80KG High Torque Digital Servo – 180° Rotation

The RDS5180 is a heavy-duty metal gear digital servo engineered for large-scale RC, robotics, and Arduino applications demanding exceptional torque and precise control. With 80KG·cm torque output and a standard 180° rotation range, it handles large control surfaces, heavy robotic arms, industrial automation rigs, and high-load pan-tilt systems with confidence.

Key Features

• 80KG·cm Torque – Heavy-duty output for large-scale and high-load applications
• 180° Rotation Range – Standard travel for precise servo control
• Full Metal Gear Train – Durable, backlash-resistant, built for longevity
• Digital Signal Processing – Faster response and higher holding torque vs. analog servos
• Dual Shaft Output – Versatile mounting for complex linkage setups
• Arduino & PWM Compatible – Works with standard 50Hz PWM signal (500–2500µs pulse width)
• High-Efficiency Motor – Optimised for sustained high-torque operation

Specifications

• Model: RDS5180
• Torque: 80KG·cm @ 6V
• Rotation: 180°
• Operating Voltage: 4.8V – 8.4V
• Signal: PWM (500–2500µs)
• Gear Material: Full Metal
• Connector: JR / Futaba compatible

Ideal For

• Large-scale RC aircraft and UAV control surfaces
• Heavy robotic arms and industrial grippers
• Arduino / Raspberry Pi high-load servo projects
• Heavy-duty pan-tilt and gimbal systems
• Custom automation and large CNC builds
