RDS51150 150KG High Torque Digital Servo 270° Metal Gear Dual Shaft

RDS51150 150KG High Torque Digital Servo – 270° Rotation

The RDS51150 is an ultra heavy-duty metal gear digital servo built for the most extreme RC, robotics, and industrial automation applications. With a massive 150KG·cm torque output and a wide 270° rotation range, this servo delivers unmatched power for large-scale control surfaces, heavy industrial robotic arms, and high-load automation systems.

Key Features

• 150KG·cm Torque – Extreme output for the most demanding heavy-load applications
• 270° Rotation Range – Extended travel for greater positional control
• Full Metal Gear Train – Heavy-duty, backlash-resistant, engineered for maximum durability
• Digital Signal Processing – Faster response and higher holding torque vs. analog servos
• Dual Shaft Output – Versatile mounting for complex high-load linkage setups
• Arduino & PWM Compatible – Works with standard 50Hz PWM signal (500–2500µs pulse width)
• High-Efficiency Motor – Optimised for sustained high-torque operation

Specifications

• Model: RDS51150
• Torque: 150KG·cm @ 6V
• Rotation: 270°
• Operating Voltage: 4.8V – 8.4V
• Signal: PWM (500–2500µs)
• Gear Material: Full Metal
• Connector: JR / Futaba compatible

Ideal For

• Large-scale RC aircraft and UAV control surfaces
• Heavy industrial robotic arms and grippers
• Arduino / Raspberry Pi ultra high-load servo projects
• Heavy-duty pan-tilt and gimbal systems
• Industrial automation and large CNC builds
