GM37RL DC Gear Motor – 6V 500RPM Low Speed High Torque Motor

GM37RL DC Gear Motor – 6V 500RPM

The GM37RL is a compact, reliable DC gear motor built for applications where controlled speed and strong torque matter more than raw RPM. Whether you're building a line-following robot, an automated slider, or a precision actuator, this motor gives you smooth, consistent output at 6V — right out of the box.

Key Features

• Low Speed, High Torque: 500RPM output with internal gear reduction delivers strong holding and driving torque for mechanical loads.
• 6V Operation: Compatible with standard Li-ion, LiPo, and regulated power supplies used in robotics and RC projects.
• 37mm Gearbox Diameter: Standard GM37 form factor — widely supported by motor mounts, brackets, and robot chassis.
• Brushed DC Design: Simple two-wire control, compatible with all standard motor drivers and H-bridge modules.
• Durable Metal Gearbox: All-metal gear train for longevity under continuous or intermittent load.
• Compact & Lightweight: Easy to integrate into tight spaces without sacrificing performance.

Specifications

• Motor Type: Brushed DC Gear Motor
• Voltage: 6V DC
• No-Load Speed: 500 RPM
• Gearbox Diameter: 37mm (GM37 series)
• Shaft: Single D-shaft output
• Control: 2-wire (forward/reverse via H-bridge or motor driver)

Common Applications

• Line-following and maze-solving robots
• Wheeled robot platforms and chassis
• Conveyor and feeder mechanisms
• Camera pan/tilt systems
• Automated doors, drawers, and sliders
• DIY CNC and motion control projects

Precise, powerful, and plug-and-play — the GM37RL is the go-to gear motor for builders who need reliable torque at a controlled speed.
