EMAX Black RS2306 2400KV BLDC FPV Racing Motor

EMAX RS2306 Black Edition – 2400KV Brushless FPV Racing Motor

The EMAX RS2306 Black Edition is a race-proven brushless motor engineered for pilots who demand peak performance on the track. With a 2400KV rating and a stator size optimized for 5-inch propellers, this motor delivers explosive thrust, razor-sharp throttle response, and the durability to survive crash after crash — because in FPV racing, it’s not if you crash, it’s when.

Key Features

• Model: RS2306 Black Edition
• KV Rating: 2400KV
• Motor Type: Brushless DC (BLDC), Outrunner
• Stator Size: 23mm diameter × 6mm height (2306)
• Recommended Propeller: 5-inch (5045 / 5148)
• Recommended Battery: 4S LiPo
• Max Thrust: ~1000g per motor (with 5045 prop on 4S)
• Motor Shaft: M5 thread, 5mm diameter
• Mounting Pattern: 16×16mm
• Weight: 30g (without wires)
• Connector: 3.5mm bullet connectors (pre-soldered)

Performance Highlights

• High-efficiency N52 magnets for maximum power output
• Titanium alloy shaft for strength and reduced weight
• Precision-balanced rotor for smooth, vibration-free operation
• Reinforced bell design to handle high-speed impacts

Ideal For

• 5-inch FPV racing quads
• Freestyle and acrobatic FPV builds
• Competitive drone racing circuits
• High-performance 4S LiPo builds

Strap the RS2306 Black Edition onto your race quad and feel the difference — instant spool-up, relentless top-end power, and the confidence to push every gate at full throttle.
