DS3235 Pro Coreless Digital Servo 35KG 270 Degree Full Metal Gear HV

DS3235 Pro Coreless Digital Servo – 35KG | 270° | Full Metal Gear | HV

The DS3235 Pro is the upgraded evolution of the popular DS3235, stepping up from a standard cored motor to a high-performance coreless motor core and extending the rotation range to a full 270°. With a commanding 35kg/cm torque output, high-voltage compatibility, and a full metal gear train, it delivers faster acceleration, smoother operation, and greater efficiency under load – making it the ideal choice for large-scale RC aircraft, heavy robotic systems, and demanding automation platforms where both power and speed of response are critical.

Key Specifications

• Model: DS3235 Pro
• Type: Coreless Digital Servo (High Voltage)
• Torque: 35 kg/cm (at 8.4V)
• Rotation Angle: 270°
• Gear Material: Full metal gears
• Motor Type: Coreless
• Control Signal: PWM digital signal
• Operating Voltage: 5V – 8.4V (HV compatible)
• Connector: Standard JR/Futaba compatible

Key Features

• Coreless motor – faster acceleration, smoother operation, and higher efficiency vs standard DS3235
• 35kg/cm torque at 8.4V – powerful performance for large-scale RC and heavy robotics
• 270° rotation range – extended travel vs the standard DS3235 (180°) for wider control authority
• High-voltage (HV) compatible – connect directly to 2S LiPo without voltage regulation loss
• Full metal gear train for maximum durability under extreme and sustained loads
• Digital control for precise positioning, minimal deadband, and strong holding torque

Applications

• Large-scale RC aircraft (main control surfaces, retract systems)
• Heavy-lift drones and UAV platforms
• Robotic arms and heavy-duty joints
• Industrial automation and motion control
• Pan-tilt systems and camera gimbals
